Features & Benefits
| Forms Pittsburgh and Snaplock seams automatically |
| Female and male seams formed independently eliminating tapered edges and duct “twist” allowing the fastest production rate in the industry |
| Large heavy-duty bearings with inner races and grease fittings protect rollformers and extend the life of the machines |
| Chain driven, heavy-duty roller transfer conveyors |
| Positive roll form feed system to ensure square formation |
| Quick changeover on female lock using a rotating rollformer frame |
| Automatic quick set for button punch on male edge |
| Material removal bypass feature allows for blank removal of sheets to be plasma cut or used for other operations |
| Heavy-duty roll form heads |
| 120" maximum and 14" minimum duct stretch-out |
| 138" maximum material stretch-out on 4-piece duct |
| 18-26-gauge mild steel capacity for Pittsburgh |
| 20-28-gauge mild steel capacity for Snaplock |
Options
| Dual head system designed to minimize footprint and maximize productivity when ship floor space is limited Automatic duct seam sealant system Industrial hard chrome plated rollform tooling |
| Extended length transfer system for additional duct stretch-out |
